fire clay bricks

Description

Fireclay bricks are the most widely used refractories made from clay minerals. It can be easily located out in the nature and contains suitable content ratio of silica,cyanite and alumina. Some people call them fireplace bricks as they are used  for building cooking chamber in wood fired ovens, for creating fireplaces, all sorts of fire boxes and wood heaters’ lining, linings in a small or the hugest industrial furnaces, you name it. Fire clay bricks have low porosity and are durable for various re-heating process.



Specifications

1. High resistance to thermal shock, abrasion, chemical attack to provide long service life;
2. High dense structure;
3. Low permanent linear change on reheating;
4. Easy operation and installation;
5. Broad usage or applications and low price, etc.



Applications

Clay bricks are mainly used in the low temperature parts of blast furnaces, waste incinerators and glass melting furnaces. Due to the scale-up of a variety of industrial furnaces and severity of operating conditions, super dense clay bricks that made of more refined chamotte being calcinated at high temperature are applied more than before. It's popular in the following furnaces:
1. Blast furnaces and hot blast furnaces
2. Waste incinerators
3. Glass melting furnaces


At Sunrise, our goal is to make the exact refractory tile the way you want. We are unique from anyone else in that we make every tile to order using recycled materials and sustainable manufacturing practices. We focus on working directly with you to create the residential and commercial project of your dreams, all in a timely manner and with the greatest customer service in the world.

Item		N-1	N-2a	N-2b	N-3a	N-3b	N-4	N-5
Refractoriness	SK	31	30	30	29	29	28	27
	℃	1750	1730	1730	1710	1710	1690	1670
Chemical composition	Al2O3	40	39	34	34	32	32	31
	Fe2O3	2.1	2.1	2.3	2.3	2.5	2.5	2.5
Apparent Porosity％		22	24	26	24	26	24	26
Bulk Density g/cm3		2.15	2.10	2.10	2.05	2.05	2.05	2.00
Cold Crushing Strength Mpa		30	25	20	20	15	20	15
0.2Mpa Refractoriness Under Load T0.6 ℃ ≥		1400	1350	1350	1320	1320	1300	1300
Reheating Linear Change	1400℃	+0.1- -0.4	+0.1- -0.5	+0.2- -0.5
	1350℃				+0.2- -0.5	+0.2- -0.5	+0.2- -0.5	+0.2- -0.5
